Amaquet Java SDK

Native Java 17+ client for a running Amaquet server. It supports Amaquet's own 24-byte-header TCP/TLS protocol v1 and its separate HTTP administration interface. The data plane is not Redis RESP and is not an HTTP API.

Requirements

• JDK 17 or later (recommended JDK 21).
• A running Amaquet server with its native port (often 13378).
• An optional separate HTTP admin endpoint (often 13379).
• An API key if your server requires native authentication.

Build and install with Maven:

mvn clean test package
mvn install

Add to a consuming Maven project's dependencies after installation:

<dependency>
  <groupId>com.newfoundcodes</groupId>
  <artifactId>amaquet</artifactId>
  <version>0.1.0</version>
</dependency>

Connect to Amaquet

import com.newfoundcodes.amaquet.*;
import java.util.*;
import java.math.BigInteger;
import java.time.Duration;

class App {
    public static void main(String[] args) {
        Client.Options options = new Client.Options()
            .apiKey(System.getenv("AMAQUET_API_KEY"))
            .timeout(Duration.ofSeconds(10))
            .maxInFlight(1024);

        try (Client db = Client.connect("amaquet://127.0.0.1:13378", options)) {
            System.out.println(db.serverInfo());
            System.out.println(db.ping());
            db.set("sample:count", "integer", 42);
            System.out.println(db.get("sample:count"));
            db.delete("sample:count");
        }
    }
}

The Client constructor establishes TCP/TLS, sends a nonce-based HELLO, verifies any supplied Ed25519 signature, and sends AUTH when credentials are supplied. If the server requests authentication and no API key is present, connection fails. The SDK does not store API keys in log messages.

A amaquets:// URI uses TLS with trusted certificate and hostname verification. To pin a server's signed identity:

Client.Options options = new Client.Options()
    .apiKey(System.getenv("AMAQUET_API_KEY"))
    .fingerprint("ed25519:YOUR_SERVER_SHA256_FINGERPRINT")
    .requireIdentity(true);
try (Client db = Client.connect("amaquets://db.example.com:13378", options)) {
    System.out.println(db.ping());
}

Do not confuse TLS certificate verification with Amaquet's separate signed HELLO identity. When using a plain amaquet:// TCP connection without identity verification, there is no transport encryption; protect it with a trusted private network or switch to TLS.

Exact integers, typed values and snapshots

try (Client db = Client.connect(uri, new Client.Options().apiKey(key))) {
    db.set("big", "unsigned_integer", new BigInteger("18446744073709551615"));
    Object snapshot = db.get("big");
    System.out.println(snapshot);

    TypedHandles.AtomicCounter counter = db.typed().generated().atomicCounter("stats:requests");
    counter.create(Json.map("initial", 0));
    counter.add(Json.map("delta", 1));
    System.out.println(counter.load());
    counter.deleteKey();
}

GET is a top-level command that returns a stored type and snapshot. A generated GET operation (for example, an array's get(Map) method) runs OP GET, not top-level GET. For operations that share method names with Java's core language, use the documented accessor: booleanType, floatType, or nullType; a barrier provides wait(Map) or waitOperation() to avoid the final Object.wait() overload.

Json.parse returns JSON integral values as BigInteger and non-integral values as BigDecimal. Use String representations for Amaquet's decimal, big_decimal, and big_integer wire types when those types require decimal string input. Do not convert money or unsigned 64-bit amounts to double.

The client does not guess the argument fields for any type. Each generated method accepts the server's exact documented argument map. See the complete type method catalog below and examples/scenarios.

Concurrent requests and cancellation

Client.Request one = db.sendCommand("GET", Json.map("key", "a"));
Client.Request two = db.sendCommand("GET", Json.map("key", "b"));
System.out.println(db.await(two));
System.out.println(db.await(one));

// Native COMMAND futures:
db.asyncCommand("INFO", Map.of()).thenAccept(System.out::println);

The read loop matches responses by 64-bit request ID, not arrival order. Use thenAcceptAsync or another asynchronous continuation for expensive callbacks: synchronous future callbacks can execute on the socket reader thread. await(request, duration) limits the wait and performs a best-effort native CANCEL for a timed-out command. The server may have committed a mutation before cancellation. The SDK does not retry writes automatically and does not claim exactly-once effects. The default number of pending commands is limited to 4,096 and configurable with maxInFlight.

Pub/Sub

try (Subscription sub = db.subscribe("event-bus", "updates", 16, 64)) {
    System.out.println(sub.next(Duration.ofSeconds(10)));
    System.out.println("Locally dropped events: " + sub.dropped());
}

Subscription events are best effort. Events may be lost at the server or SDK when consumers are slow. An explicit unsubscribe releases the subscription, and closing the client removes all subscriptions.

Chunked blob transfers

byte[] bytes = java.nio.file.Files.readAllBytes(java.nio.file.Path.of("payload.bin"));
db.uploadBlob("payload", bytes);
byte[] copy = db.downloadBlobBytes("payload", 32 * 1024 * 1024);

java.nio.file.Path inputPath = java.nio.file.Path.of("large.bin");
long fileSize = java.nio.file.Files.size(inputPath);
try (var input = java.nio.file.Files.newInputStream(inputPath)) {
    db.uploadBlob("large-payload", input, fileSize, 1 << 20, false);
}
try (var out = java.nio.file.Files.newOutputStream(java.nio.file.Path.of("large-copy.bin"))) {
    db.downloadBlob("large-payload", out, 1 << 20, 1L << 30);
}

The streaming uploader consumes exactly the declared byte count; it does not wait for a source to reach EOF. Do not modify a blob during streaming reads. The downloader checks total size and version for every range.

HTTP administration

AdminClient admin = new AdminClient("https://db.example.com:13379", System.getenv("AMAQUET_ADMIN_TOKEN"));
System.out.println(admin.health());
System.out.println(admin.apiKeys());
System.out.println(admin.dataKeys("", "", 100));

The admin API is distinct from the native protocol and has its own authentication and permissions. Its complete 33-route catalog is included below.

Running examples

The repository contains 91 type examples and 42 standalone workflow examples. After running mvn package, compile the examples against the built library:

find examples -name '*.java' | sort > target/example-sources.txt
javac --release 17 -cp target/classes -d target/examples @target/example-sources.txt
java -cp target/classes:target/examples Workflow01Connect
java -cp target/classes:target/examples Workflow03ExactIntegers
java -cp target/classes:target/examples ExampleAtomicCounter

Configure AMAQUET_URL, AMAQUET_API_KEY, AMAQUET_ADMIN_URL, and AMAQUET_ADMIN_TOKEN. The equivalent C# and Go examples use AMAQUET_ENDPOINT and AMAQUET_URI for the native URI. Type examples create the documented type by default. Set AMAQUET_RUN_OPERATIONS=true to run its documented operations, which can mutate or block. Use a dedicated test server.

Native protocol and security

Amaquet v1 uses a fixed 24-byte, big-endian header. Payloads are JSON and the data plane is not Redis RESP or HTTP.

Offset	Size	Field	Description
0	4	Magic	ASCII AMQT
4	1	Version	Protocol version 1
5	1	Kind	Request, response, or event
6	2	Flags	Unsigned 16-bit flags
8	2	Opcode	COMMAND, HELLO, AUTH, SUBSCRIBE, UNSUBSCRIBE, or CANCEL
10	2	Reserved	Must be zero
12	8	Request ID	Unsigned big-endian request identifier
20	4	Payload length	Unsigned length, capped at 64 MiB

Responses use { "ok": true, "result": value } or { "ok": false, "error": { "code": "...", "message": "..." } }. Malformed frames, unknown versions, opcode mismatches, invalid reserved bytes, unexpected frames, and oversized payloads close the connection.

The client uses a background reader and correlates responses by request ID, so commands may complete out of order. Writes are serialized, requests are bounded by maxInFlight, and subscriptions use bounded non-blocking queues. Queue overflow is reported by Subscription.dropped(); event delivery is best effort.

TLS uses JSSE certificate-chain and hostname verification. Amaquet also signs the HELLO challenge with Ed25519; this identity is independent of the TLS certificate and can be required or pinned with a public key or fingerprint. Native API keys should be supplied with Client.Options.apiKey(). URI credentials are rejected by default. HTTP administration credentials are separate from native credentials, redirects are not followed, and response bodies are bounded before parsing.

The SDK does not automatically retry reads or writes. A timeout or cancellation does not undo a mutation that may already have reached the server.

Failure types

• AmaquetException.Protocol: malformed frames, unexpected responses, or identity verification errors.
• AmaquetException.Request: a server response with ok: false.
• AmaquetException.Timeout: a command exceeded its deadline; a mutation may already be committed.
• AmaquetException.Transport: socket or stream I/O failure.
• AmaquetException.Http: a non-2xx administration response with status and body details.
• IllegalArgumentException: invalid configuration, unsafe paths, malformed JSON, or invalid local arguments.

HTTP administration route catalog

The administration server is a separate HTTP(S) endpoint. AdminClient uses JDK HttpClient, disables redirects, bounds response bodies, and supports Bearer tokens, X-Amaquet-Admin-Token, and the amaquet_session cookie.

AdminClient admin = new AdminClient("https://db.example.com:13379",
    System.getenv("AMAQUET_ADMIN_TOKEN"));
System.out.println(admin.health());
System.out.println(admin.audit(100));

Method	Path	Java method
DELETE	/api/api-keys/{id}	revokeApiKey(id)
DELETE	/api/data/key	deleteDataKey(key)
DELETE	/api/identity/mfa	disableMfa(code)
DELETE	/api/members/{id}	deleteMember(id)
DELETE	/api/session	deleteSession()
GET	/api/api-keys	apiKeys()
GET	/api/audit	audit(limit)
GET	/api/auth/check	checkAuth()
GET	/api/data/key	dataKey(key)
GET	/api/data/keys	dataKeys(cursor,prefix,count)
GET	/api/health	health()
GET	/api/members	members()
GET	/api/organization	organization()
GET	/api/overview	overview()
GET	/api/rbac	rbac()
GET	/api/ready	ready()
GET	/api/system	system()
GET	/metrics	metrics()
GET	/openapi.json	openapi()
PATCH	/api/members/{id}	patchMember(id,role,status)
POST	/api/api-keys	createApiKey(name,role,expiresAt)
POST	/api/data/command	dataCommand(command,args)
POST	/api/identity/accept-invite	acceptInvite(invite)
POST	/api/identity/mfa	beginMfa()
POST	/api/members	addMember(name,email,role)
POST	/api/members/{id}/invite	inviteMember(id,hours)
POST	/api/persistence/checkpoint	checkpoint(name)
POST	/api/persistence/compact	compact()
POST	/api/session	createSession(token,mfaCode)
PUT	/api/identity/mfa	confirmMfa(code)
PUT	/api/organization	updateOrganization(name,slug)
PUT	/api/rbac	updateRbac(config)
PUT	/api/system	updateSystem(config)

There are exactly 33 documented method/path combinations. Route parameters are encoded as single path segments; traversal and unsafe inputs are rejected. Successful session creation stores the session cookie for later requests. Non-2xx responses throw AmaquetException.Http; empty successful bodies return null, /metrics returns text, and JSON routes return parsed Java values.

Complete type operation catalog

Typed access is client.typed().generated().atomicCounter(key), or client.typed().forType("atomic_counter", key). Construction and snapshots use top-level CREATE, SET, and GET; every operation in this table maps to native OP. Methods accept the server's exact Map<String,Object> arguments.

Wire type	Java accessor	Generated OP methods
adjacency_set	adjacencySet(key)	add, neighbors, remove
aggregated_series	aggregatedSeries(key)	aggregate, range
array	array(key)	append, get, len, set, values
atomic_counter	atomicCounter(key)	add, cas, load
barrier	barrier(key)	wait
big_decimal	bigDecimal(key)	add, cmp, sub
big_integer	bigInteger(key)	add
binary_string	binaryString(key)	top-level methods
bit_field	bitField(key)	set, get
bit_set	bitSet(key)	set, getbit, count
bitmap	bitmap(key)	set, getbit, count
blocking_queue	blockingQueue(key)	enqueue, dequeue, close, len
bloom_filter	bloomFilter(key)	add, contains
boolean	booleanType(key)	toggle
bounding_box	boundingBox(key)	contains
btree_index	btreeIndex(key)	insert, search, delete, range
cbor	cbor(key)	get
cidr_network	cidrNetwork(key)	contains
consumer_group	consumerGroup(key)	snapshot
count_min_sketch	countMinSketch(key)	add, estimate
counter_series	counterSeries(key)	add, last, aggregate, len, range
counting_bloom_filter	countingBloomFilter(key)	add, contains, remove
cuckoo_filter	cuckooFilter(key)	add, contains, remove
decimal	decimal(key)	add, cmp, sub
delayed_queue	delayedQueue(key)	enqueue, popReady, len
dense_vector	denseVector(key)	distance
deque	deque(key)	pushBack, pushFront, len, popFront, popBack, values
duration	duration(key)	add
event_log	eventLog(key)	append, len, read
fifo_queue	fifoQueue(key)	enqueue, peek, dequeue, len
flat_vector_index	flatVectorIndex(key)	add, search, remove, len
float	floatType(key)	add
full_text_document	fullTextDocument(key)	addText, addTag, addNumeric, snapshot, get
gauge_series	gaugeSeries(key)	set, last, range, aggregate, len
geo_point	geoPoint(key)	distance
geo_spatial_index	geoSpatialIndex(key)	add, radius, remove, box, polygon
geospatial_secondary_index	geospatialSecondaryIndex(key)	add, radius, remove, box, polygon
hash_index	hashIndex(key)	add, lookup, remove
hashmap	hashmap(key)	set, get, delete, keys
histogram	histogram(key)	observe, snapshot
hnsw_index	hnswIndex(key)	add, search, remove
hyperloglog	hyperloglog(key)	add, count
integer	integer(key)	add
inverted_index	invertedIndex(key)	index, search, remove
json	json(key)	set, get
lease	lease(key)	acquire, held, release, renew
lifo_stack	lifoStack(key)	push, peek, pop, len
list	list(key)	pushBack, pushFront, len, range, popFront, popBack
lock	lock(key)	tryLock, unlock, renew
matrix	matrix(key)	get, set, len
messagepack	messagepack(key)	get
multimap	multimap(key)	add, get, remove
multiset	multiset(key)	add, count, remove
null	nullType(key)	top-level methods
numeric_field	numericField(key)	set, get
ordered_map	orderedMap(key)	set, get, delete, entries
ordered_set	orderedSet(key)	add, values, remove
persistent_topic	persistentTopic(key)	publish, read
polygon	polygon(key)	contains
priority_queue	priorityQueue(key)	enqueue, len, dequeue
pubsub	pubsub(key)	publish, stats
quantized_vector	quantizedVector(key)	dequantize
radix_tree	radixTree(key)	insert, prefix, exact
rate_limit_bucket	rateLimitBucket(key)	allow, remaining
record	record(key)	set, get
reliable_queue	reliableQueue(key)	enqueue, claim, ack, nack, stats
ring_buffer	ringBuffer(key)	push, len, values
roaring_bitmap	roaringBitmap(key)	add, contains, cardinality, remove, values
secondary_index	secondaryIndex(key)	add, lookup
semaphore	semaphore(key)	tryAcquire, stats, release, acquire
set	set(key)	add, contains, remove, members, len
sorted_set	sortedSet(key)	add, score, remove, range
sparse_vector	sparseVector(key)	top-level methods
stream	stream(key)	add, range, groupCreate, groupRead, ack, pending, len
symbol	symbol(key)	top-level methods
t_digest	tDigest(key)	add, quantile
tag_field	tagField(key)	set, get
tensor	tensor(key)	get, set, len
text_field	textField(key)	set, get
timeseries	timeseries(key)	add, len, range, last, aggregate
timeseries_labels	timeseriesLabels(key)	set, get
timestamp	timestamp(key)	top-level methods
top_k	topK(key)	add, items
trie	trie(key)	insert, prefix, exact
tuple	tuple(key)	len, get, values
unsigned_integer	unsignedInteger(key)	add
url	url(key)	host, scheme
utf8_string	utf8String(key)	top-level methods
uuid	uuid(key)	top-level methods
vector_metadata	vectorMetadata(key)	set, get, delete
vector_set	vectorSet(key)	add, search, remove, len

There are 91 registered types and 242 documented type-specific operations. Operation names are transmitted uppercase and unchanged. Java's reserved names use booleanType, floatType, and nullType; the barrier handle provides wait(Map) and waitOperation() because zero-argument wait() belongs to Object. The 91 Example<Type>.java programs and JSON scenarios contain the documented construction payloads and operation arguments.

Testing and live verification

The SDK has Maven/JUnit 5 tests backed by controlled local peers. The default test suite does not contact an external server.

mvn clean test package

The regression suite covers request-ID multiplexing, all 242 generated operations, 91 construction payloads, 33 administration routes, exact-number JSON, signed Ed25519 HELLO, cancellation, Pub/Sub drops, binary transfer, pooling, error conversion, and malformed frames. The fuzz harness has 13 deterministic targets for JSON, UTF-8, frame parsing, endpoint parsing, administration paths, expiration options, Base64 identity fields, and precise numeric values. This is deterministic mutation testing, not coverage-guided JVM fuzzing.

For TLS or fuzz smoke tests, compile the test classes and invoke their Java entry points directly:

mvn test-compile
java -cp target/classes:target/test-classes com.newfoundcodes.amaquet.TlsTest
java -cp target/classes:target/test-classes com.newfoundcodes.amaquet.FuzzTargets 2000

For live verification, use a dedicated disposable Amaquet deployment and invoke the opt-in test directly:

export AMAQUET_TEST_URL=amaquet://127.0.0.1:13378
export AMAQUET_TEST_API_KEY='your-test-api-key'
mvn test-compile
java -cp target/classes:target/test-classes com.newfoundcodes.amaquet.LiveTest

The live suite checks TYPES, constructs all 91 types under unique keys, reads each snapshot, removes the test keys, and performs a binary round trip. Set AMAQUET_TEST_ALL_OPS=1 only after reviewing operation prerequisites and side effects; some operations block or mutate state. An optional AMAQUET_TEST_IDENTITY_FINGERPRINT pins the server identity.

Mock tests do not prove every server-side type mutation. Applications should also test permissions, backpressure, network partitions, restarts, persistence, and real TLS certificates in their deployment environment.

License

Amaquet Java SDK is licensed under the MIT License. See LICENSE.
